如果教程中代码不便于阅读，请使用电脑查看或点击阅读原文。
0. 开发环境
-
JDK：1.8
-
Spring Boot：2.1.1.RELEASE
1. 引入依赖
<dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-websocket</artifactId> </dependency>
2. 新建WebSocket配置类
import org.springframework.context.annotation.Bean;import org.springframework.context.annotation.Configuration;import org.springframework.web.socket.server.standard.ServerEndpointExporter;@Configurationpublic class WebSocketConfig { /** * ServerEndpointExporter注入 * 该Bean会自动注册使用@ServerEndpoint注解申明的WebSocket endpoint * * @return */ @Bean public ServerEndpointExporter serverEndpointExporter() { return new ServerEndpointExporter(); }}
3. 新建WebSocket服务类
package cn.wbnull.springbootdemo.service;import org.slf4j.Logger;import org.slf4j.LoggerFactory;import org.springframework.stereotype.Component;import javax.websocket.*;import javax.websocket.server.PathParam;import javax.websocket.server.ServerEndpoint;import java.io.IOException;import java.util.Map;import java.util.concurrent.ConcurrentHashMap;@Component@ServerEndpoint("/websocket/{terminalId}")public class WebSocketService { private final Logger logger = LoggerFactory.getLogger(WebSocketService.class); /** * 保存连接信息 */ private static final Map<String, Session> CLIENTS = new ConcurrentHashMap<>(); @OnOpen public void onOpen(@PathParam("terminalId") String terminalId, Session session) throws Exception { logger.info(session.getRequestURI().getPath() + "，打开连接开始：" + session.getId()); //当前连接已存在，关闭 if (CLIENTS.containsKey(terminalId)) { onClose(CLIENTS.get(terminalId)); } CLIENTS.put(terminalId, session); logger.info(session.getRequestURI().getPath() + "，打开连接完成：" + session.getId()); } @OnClose public void onClose(@PathParam("terminalId") String terminalId, Session session) throws Exception { logger.info(session.getRequestURI().getPath() + "，关闭连接开始：" + session.getId()); CLIENTS.remove(terminalId); logger.info(session.getRequestURI().getPath() + "，关闭连接完成：" + session.getId()); } @OnMessage public void onMessage(String message, Session session) { logger.info("前台发送消息：" + message); } @OnError public void onError(Session session, Throwable error) { logger.error(error.toString()); } public void onClose(Session session) { //判断当前连接是否在线// if (!session.isOpen()) {// return;// } try { session.close(); } catch (IOException e) { logger.error("金斗云关闭连接异常：" + e); } } public void sendMessage(String message, Session session) { try { session.getAsyncRemote().sendText(message); logger.info("推送成功：" + message); } catch (Exception e) { logger.error("推送异常：" + e); } } public boolean sendMessage(String terminalId, String message) { try { Session session = CLIENTS.get(terminalId); session.getAsyncRemote().sendText(message); logger.info("推送成功：" + message); return true; } catch (Exception e) { logger.error("推送异常：" + e); return false; } }}
4. 新建Web端连接页面
<!DOCTYPE html><html lang="en"><head> <meta charset="UTF-8"> <title>WebSocket Test</title></head><body><label for="text"></label><input id="text" type="text"/><button onclick="sendMessage()">发送消息</button><button onclick="closeWebSocket()">关闭连接</button><div id="message"></div></body><script type="text/javascript"> let websocket = null; //判断当前浏览器是否支持WebSocket if ('WebSocket' in window) { websocket = new WebSocket("ws://localhost:8090/websocket/123456"); } else { alert('Not support websocket'); } //连接发生错误的回调方法 websocket.onerror = function () { showMessage("打开连接失败"); }; //连接成功建立的回调方法 websocket.onopen = function (event) { showMessage("打开连接成功"); } //接收到消息的回调方法 websocket.onmessage = function (event) { showMessage(event.data); } //连接关闭的回调方法 websocket.onclose = function () { showMessage("关闭连接成功"); } //监听窗口关闭事件，当窗口关闭时，主动关闭WebSocket连接 window.onbeforeunload = function () { websocket.close(); } function showMessage(message) { document.getElementById('message').innerHTML += message + '<br/>'; } function closeWebSocket() { websocket.close(); } //发送消息 function sendMessage() { const message = document.getElementById('text').value; websocket.send(message); }</script></html>
5. 设置后端消息推送
为便于测试，直接修改WebSocketService，当收到前台消息时，直接给前台发送消息
@OnMessage public void onMessage(String message, Session session) { logger.info("前台发送消息：" + message); sendMessage("收到消息：" + message, session); }
6. 测试
浏览器访问http://127.0.0.1:8090/，页面显示如下：
后台日志如下：
2022-07-02 21:03:22.753 INFO 9168 --- [nio-8090-exec-2] c.w.s.service.WebSocketService : /websocket/123456，打开连接开始：02022-07-02 21:03:22.753 INFO 9168 --- [nio-8090-exec-2] c.w.s.service.WebSocketService : /websocket/123456，打开连接完成：0
当我们浏览器打开第二个页面，第一个页面会显示断开连接
后台日志如下：
2022-07-02 21:04:01.936 INFO 9168 --- [nio-8090-exec-4] c.w.s.service.WebSocketService : /websocket/123456，打开连接开始：12022-07-02 21:04:01.938 INFO 9168 --- [nio-8090-exec-4] c.w.s.service.WebSocketService : /websocket/123456，关闭连接开始：02022-07-02 21:04:01.938 INFO 9168 --- [nio-8090-exec-4] c.w.s.service.WebSocketService : /websocket/123456，关闭连接完成：02022-07-02 21:04:01.938 INFO 9168 --- [nio-8090-exec-4] c.w.s.service.WebSocketService : /websocket/123456，打开连接完成：1
前台页面录入消息并发送，后台可正常收到消息
2022-07-02 21:08:21.860 INFO 1772 --- [nio-8090-exec-3] c.w.s.service.WebSocketService : 前台发送消息：测试消息2022-07-02 21:08:21.863 INFO 1772 --- [nio-8090-exec-3] c.w.s.service.WebSocketService : 推送成功：收到消息：测试消息
前台页面显示正常
点击关闭连接，可以正常关闭
7. 服务保活
对于实时消息推送相关服务，都存在保活问题。这里我们采用心跳保活。修改WebSocketService类
import org.slf4j.Logger;import org.slf4j.LoggerFactory;import org.springframework.stereotype.Component;import javax.websocket.*;import javax.websocket.server.PathParam;import javax.websocket.server.ServerEndpoint;import java.io.IOException;import java.util.HashMap;import java.util.Map;import java.util.concurrent.ConcurrentHashMap;import java.util.concurrent.atomic.AtomicInteger;@Component@ServerEndpoint("/websocket/{terminalId}")public class WebSocketService { private final Logger logger = LoggerFactory.getLogger(WebSocketService.class); /** * 保存连接信息 */ private static final Map<String, Session> CLIENTS = new ConcurrentHashMap<>(); private static final Map<String, AtomicInteger> TERMINAL_IDS = new HashMap<>(); @OnOpen public void onOpen(@PathParam("terminalId") String terminalId, Session session) throws Exception { logger.info(session.getRequestURI().getPath() + "，打开连接开始：" + session.getId()); //当前连接已存在，关闭 if (CLIENTS.containsKey(terminalId)) { onClose(CLIENTS.get(terminalId)); } TERMINAL_IDS.put(terminalId, new AtomicInteger(0)); CLIENTS.put(terminalId, session); logger.info(session.getRequestURI().getPath() + "，打开连接完成：" + session.getId()); } @OnClose public void onClose(@PathParam("terminalId") String terminalId, Session session) throws Exception { logger.info(session.getRequestURI().getPath() + "，关闭连接开始：" + session.getId()); CLIENTS.remove(terminalId); TERMINAL_IDS.remove(terminalId); logger.info(session.getRequestURI().getPath() + "，关闭连接完成：" + session.getId()); } @OnMessage public void onMessage(String message, Session session) { logger.info("前台发送消息：" + message); if ("心跳".equals(message)) { //重置当前终端心跳次数 TERMINAL_IDS.get(message).set(0); return; } sendMessage("收到消息：" + message, session); } @OnError public void onError(Session session, Throwable error) { logger.error(error.toString()); } public void onClose(Session session) { //判断当前连接是否在线// if (!session.isOpen()) {// return;// } try { session.close(); } catch (IOException e) { logger.error("金斗云关闭连接异常：" + e); } } public void heartbeat() { //检查所有终端心跳次数 for (String key : TERMINAL_IDS.keySet()) { //心跳3次及以上的主动断开 if ((TERMINAL_IDS.get(key).intValue() >= 3)) { logger.info("心跳超时，关闭连接：" + key); onClose(CLIENTS.get(key)); } } for (String key : CLIENTS.keySet()) { //记录当前终端心跳次数 TERMINAL_IDS.get(key).incrementAndGet(); sendMessage("心跳", CLIENTS.get(key)); } } public void sendMessage(String message, Session session) { try { session.getAsyncRemote().sendText(message); logger.info("推送成功：" + message); } catch (Exception e) { logger.error("推送异常：" + e); } } public boolean sendMessage(String terminalId, String message) { try { Session session = CLIENTS.get(terminalId); session.getAsyncRemote().sendText(message); logger.info("推送成功：" + message); return true; } catch (Exception e) { logger.error("推送异常：" + e); return false; } }}
8. 新增定时任务
新增定时任务，定时给连接到WebSocket的终端发送消息，超过指定次数未回应的终端视为离线，主动关闭连接。
import cn.wbnull.springbootdemo.service.WebSocketService;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.scheduling.annotation.EnableScheduling;import org.springframework.scheduling.annotation.Scheduled;import org.springframework.stereotype.Component;@EnableScheduling@Componentpublic class WebSocketScheduled { @Autowired private WebSocketService webSocketService; @Scheduled(cron = "0/15 * * * * ?") public void heartbeat() { webSocketService.heartbeat(); }}
同样的，前台也需要定时心跳WebSocket，这里不做赘述。
9. Bean注入
WebSocket服务类中，使用@Autowired直接注入Service或普通Bean时，会报空指针错误。这是因为Spring管理对象时使用单例模式，但WebSocket服务为多对象。
Spring Boot项目在启动初始化时，会初始化非用户连接的WebSocket服务，为其注入Service，此时使用@Autowired注入的Service不为null，即被成功注入。但，Spring默认管理的是单例，所以只会注入一次Service。当新用户连接时，系统又会创建一个新的WebSocket对象，Spring就不会给第二个 WebSocket对象注入Service了，所以导致只要是用户连接创建的WebSocket 对象，都不能再注入了。
import org.slf4j.Logger;import org.slf4j.LoggerFactory;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.stereotype.Component;import javax.websocket.*;import javax.websocket.server.PathParam;import javax.websocket.server.ServerEndpoint;import java.io.IOException;import java.util.HashMap;import java.util.Map;import java.util.concurrent.ConcurrentHashMap;import java.util.concurrent.atomic.AtomicInteger;@Component@ServerEndpoint("/websocket/{terminalId}")public class WebSocketService { //code /** * 需要注入的Service声明为静态，让其属于类 */ private static TerminalService terminalService; /** * 注入的时候，给类的Service注入 */ @Autowired public void setMchDeviceInfoService(TerminalService terminalService) { WebSocketService.terminalService = terminalService; } @OnOpen public void onOpen(@PathParam("terminalId") String terminalId, Session session) throws Exception { //code terminalService.terminal(); } //code}
测试日志打印如下
2022-07-02 21:26:08.166 INFO 9924 --- [nio-8090-exec-2] c.w.s.service.WebSocketService : /websocket/123456，打开连接开始：02022-07-02 21:26:08.166 INFO 9924 --- [nio-8090-exec-2] c.w.s.service.WebSocketService : /websocket/123456，打开连接完成：02022-07-02 21:26:08.166 INFO 9924 --- [nio-8090-exec-2] c.w.s.service.TerminalService : 这是一条测试日志
GitHub：https://github.com/dkbnull/SpringBootDemo
CSDN：https://blog.csdn.net/dkbnull/article/details/125577993
